How are Solar Panels Made?

Here’s a comprehensive guide on how solar panels are made in the UK.

Solar panels, also known as photovoltaic (PV) panels, are composed of multiple solar cells that convert sunlight into electricity. The manufacturing process of solar panels involves several key steps, from raw material processing to final assembly.

1. Silicon Refining

Raw Material:

The primary material used in solar cells is silicon, derived from sand (silicon dioxide).

Purification:

Silicon dioxide is processed into metallurgical-grade silicon by heating it in a furnace with carbon at high temperatures.
The metallurgical-grade silicon is further purified into solar-grade silicon through a chemical purification process known as the Siemens process, which involves converting it into trichlorosilane gas and then back into high-purity silicon.

2. Ingot Production

Creating Silicon Ingots:

Purified silicon is melted in a crucible.
A seed crystal is dipped into the molten silicon and slowly pulled out, allowing the silicon to crystallize around it. This process forms a cylindrical ingot of single-crystal silicon (monocrystalline) or a block of multi-crystalline silicon (polycrystalline).

Cooling and Cutting:

The ingot is carefully cooled and then sliced into thin wafers using a wire saw. These wafers are the raw material for solar cells.

3. Wafer Fabrication

Cleaning and Texturizing:

The silicon wafers are cleaned to remove any contaminants.
The surface of the wafers is textured to reduce reflectivity and increase light absorption. This is typically done through a chemical etching process.

Doping:

To create the p-n junction, which is essential for converting sunlight into electricity, the wafers are doped with phosphorous (n-type) and boron (p-type) to create positive and negative charge carriers.

4. Solar Cell Manufacturing

Anti-Reflective Coating:

A thin anti-reflective coating, usually made of silicon nitride, is applied to the wafer to improve light absorption.

Metal Contacts:

Fine metal contacts (usually silver) are printed onto the front and back of the wafer. These contacts collect and conduct the electricity generated by the solar cell.

Testing and Sorting:

The completed solar cells are tested for efficiency and electrical characteristics. They are then sorted based on their performance.

5. Assembling Solar Panels

Cell Interconnection:

Solar cells are interconnected using conductive ribbons to form a solar module. The cells are soldered together in a series to achieve the desired voltage and current.

Encapsulation:

The interconnected cells are encapsulated to protect them from environmental damage. The encapsulation process involves sandwiching the cells between layers of protective materials, typically ethylene vinyl acetate (EVA) on the front and back.

Framing and Lamination:

The encapsulated cells are laminated under heat and pressure to bond the layers together.
A protective backsheet is added to the back of the module, and a tempered glass layer is placed on the front to shield the cells from physical damage.
The assembly is then framed with aluminum to provide structural support and ease of installation.

Junction Box:

A junction box is attached to the back of the panel. This box contains the electrical connections and provides a secure point for external wiring.

6. Quality Control and Testing

Inspection:

Each solar panel undergoes rigorous quality control tests to ensure it meets industry standards and performance specifications. Tests include visual inspections, electrical performance tests, and mechanical load tests.

Performance Testing:

Solar panels are tested under standard test conditions (STC) to measure their power output, efficiency, and overall performance.

7. Packaging and Distribution

Packaging:

After passing all quality control checks, the solar panels are carefully packaged to prevent damage during transportation.

Distribution:

Packaged solar panels are then distributed to retailers, installers, and customers across the UK and other regions.

Conclusion

The manufacturing process of solar panels involves a series of sophisticated steps, from refining silicon to assembling and testing the final product. Each step is crucial to ensure the panels are efficient, durable, and capable of generating clean, renewable energy. The UK's focus on quality and innovation in solar panel manufacturing ensures that the end products meet high standards, contributing to the growing adoption of solar energy and supporting the transition to a more sustainable future.
